Attached Hose 10 ft (305 cm) dual hose. Connectors allow pads to be
connected to the pump
Tip-over Turns heater off if pump is tipped.
Switch NOTE: This does not activate the OVER TEMP light.
Hospital ID A label is provided on the back of the T/Pump for your
Label convenience. Use a felt tip or ball point pen to add any
required hospital identification.
OVER TEMP Indicates the pump and heater have been turned off.
Light This light is activated by the two OVER TEMP safety
thermostats. Refer to the TROUBLESHOOTING section.
Circuit Breaker When the circuit breaker trips, the small button in
the center will extend 1/4", exposing a white band.
Refer to the TROUBLESHOOTING section.
OVER TEMP Either of two limit thermostats will shut off pump and
Safety heater if the high temperature limit is exceeded. The
Thermostats OVER TEMP light will glow. Refer to the TROUBLESHOOTING
Dimensions:
Type: Warm Water Circulation Pump
Manufacture: Gaymar
Size: 6"x5"x5"
Weight: 4lbs
